• 2-speed transfer case
• Four wheel drive
• HD Gas-Pressurized Shock Absorbers
• Pwr steering

5.8L (351) MFI V8 ENGINE

• (STD)

• Four Wheel Drive
• Four Wheel Drive
• Tires - Front All-Season
• Tires - Rear All-Season
• Power Steering
• ABS
• Intermittent Wipers
• Vinyl Seats
• Fixed Bench Seat
• Power Outlet
• ABS

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 650
• Maximum Alternator Capacity (amps): 95
• Maximum Alternator Watts: 1425
• Cooling System
• Total Cooling System Capacity (qts): 15
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3305
• Gross Axle Wt Rating - Rear (lbs): 6084
• Curb Weight - Front (lbs): 2871
• Curb Weight - Rear (lbs): 2131
• Gross Vehicle Weight Rating Cap (lbs): 8600
• Gross Combined Wt Rating (lbs): 11,500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 2000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 200
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 2000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 300
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 2000
• Suspension
• Suspension Type - Front: 1-Stage Multi-Leaf
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 3305
• Spring Capacity - Rear (lbs): 6148
• Axle Type - Front: Twin Traction-Beam
• Axle Type - Rear: Ford Full-Floating
• Axle Capacity - Front (lbs): 4600
• Axle Capacity - Rear (lbs): 6250
• Axle Ratio (:1) - Front: 3.55
• Axle Ratio (:1) - Rear: 3.55
• Shock Absorber Diameter - Front (mm): 35.1
• Shock Absorber Diameter - Rear (mm): 35.1
• Brakes
• Brake Type: Power
• Brake ABS System: Rear Wheel
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.96 x 1.79
• Drum - Rear (Yes or ): Yes
• Rear Drum Diam x Width (in): 12 x 3.0
• Tires
• Front Tire Order Code: T35
• Rear Tire Order Code: T35
• Front Tire Size: LT235/85R16E
• Rear Tire Size: LT235/85R16E
• Front Tire Capacity (lbs): 3042
• Rear Tire Capacity (lbs): 3042
• Revolutions/Mile @ 45 mph - Front: 654
• Revolutions/Mile @ 45 mph - Rear: 654
• Wheels
• Front Wheel Size (in): 16.0 x 7.0
• Rear Wheel Size (in): 16.0 x 7.0
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Steering
• Steering Type: Power
• Steering Ratio (:1), On Center: 17.0
• Turning Diameter - Curb to Curb (ft): 46.32
• Turning Diameter - Wall to Wall (ft): 48.50
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 18.2
• Aux Fuel Tank Capacity, Approx (gal): 16.5
• Fuel Tank Location: Aft-of-axle
• Aux Fuel Tank Location: Midship
• Exterior Dimensions
• Wheelbase (in): 133.0
• Length, Overall w/o rear bumper (in): 213.3
• Width, Max w/o mirrors (in): 79.0
• Height, Overall (in): 76.6
• Overhang, Front (in): 33.5
• Overhang, Rear w/o bumper (in): 46.8
• Front Bumper to Back of Cab (in): 110.3
• Cab to Axle (in): 56.2
• Cab to End of Frame (in): 96.6
• Ground to Top of Load Floor (in): 35.1
• Frame Width, Rear (in): 37.6
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 98.2
• Cargo Box Width @ Top, Rear (in): 64.9
• Cargo Box Width @ Floor (in): 70.0
• Cargo Box Width @ Wheelhousings (in): 50.8
• Cargo Box (Area) Height (in): 19.3
• Tailgate Width (in): 64.9
• Cargo Volume (ft³): 75.6
• Interior Dimensions
• Passenger Capacity: 3
• Front Head Room (in): 40.3
• Front Leg Room (in): 41.1
• Front Shoulder Room (in): 64.8
• Front Hip Room (in): 62.2
• Summary
• Vehicle Name: Ford F-250
• Body Style: Reg Cab 8' Styleside
• Body Code: 133.0" WB
